Deaf Bonce Machete 520W 4 ohm 2CH Class D Full Range Amplifier MFA-2.520

• High-Performance Output: Delivers 520W RMS per channel at 4 Ohms and can be bridged to 1500W
• Flexible Configuration: Suitable for various setups with different channel loads
• Precise Audio Control: Low and high pass filters for accurate sound shaping
• Efficient Class D Design: Maximizes power in a compact form
• Superior Sound Quality: Maintains clarity with a high signal-to-noise ratio

Deaf Bonce Machete 520W 4 ohm 2-Channel Class D Full Range Amplifier MFA-2.520

This Listing Includes:

• (1) Machete MFA-2.520 Power Amplifier

The Machete MFA-2.520 stands out as a versatile and powerful 2-channel Class D amplifier, perfect for audiophiles seeking superior performance in their car audio systems. With 520 watts RMS power per channel at 4 Ohms and the capability to bridge up to 1500 watts, it offers exceptional flexibility for different speaker configurations. The amplifier includes both low and high pass filters, allowing for precise audio tuning across a broad frequency range.

Specifications:

• Model: MFA-2.520
• Class: D
• Number of Channels: 2
• Frequency Response: 20-20000 Hz
• 2 Ohm RMS Power (14.4 V): 750 W x 2
• 4 Ohm RMS Power (14.4 V): 520 W x 2
• 4 Ohm RMS Power (Bridge): 1500 W x 1
• Minimum Permissible Load on the Channel: 2 Ohm
• Minimum Permissible Load in a Bridge Connection: 4 Ohm
• Low Pass Filter: 50-12000 Hz
• High Pass Filter: 50-12000 Hz
• Input SPL: 0.4 - 8V
• Crossover: 12 dB/Oct
• Input Terminal: 4 Ga
• Output Terminal: 8 Ga
• Working Voltage: 9 - 15V
• Signal-to-Noise Ratio: â 90 dB
• Size (WxLxH): 11 x 6 x 2.2 inches

Features:

• Versatile 2-channel power handling
• Bridgeable for enhanced subwoofer power
• Comprehensive audio customization with filters
• High signal-to-noise ratio for audio clarity
• Compact and efficient Class D amplifier design
