DS18 Dual 12" Loaded Subwoofer Ported Enclosure With ZR12.4D 1500 Watts Rms

DS18 Dual 12” Loaded Subwoofer Enclosure ZR12.4D 3000W MAX 1500W RMS 1-Ohm Ported Box

Key Features

• Dual 12” Subwoofer System – Includes (2) DS18 ZR12.4D subwoofers for powerful bass output.
• High Power Handling – Delivers 1500W RMS / 3000W MAX for deep, aggressive bass.
• 1-Ohm Final Impedance – Wired in parallel for maximum amplifier efficiency and output.
• Ported Box Tuned to 29Hz – Designed for low, hard-hitting bass performance.
• Durable Construction – Built with 3/4" MDF for strength and optimal sound quality.
• Clean & Loud Performance – Balanced output with reduced distortion and strong low-end response.

Product Description

Upgrade your system with the DS18 Dual 12” Loaded Subwoofer Enclosure with ZR12.4D subwoofers, built to deliver powerful, deep, and clean bass.

This enclosure comes preloaded with two ZR12.4D subwoofers, each featuring a dual 2-ohm voice coil, wired in parallel to achieve a 1-ohm final load. This setup allows your amplifier to deliver maximum power efficiently, resulting in louder output with less distortion.

Handling 1500W RMS and 3000W MAX, this system is perfect for users looking for strong bass performance without stepping into extreme competition builds.

The enclosure is constructed from high-quality 3/4" MDF and tuned to 29Hz, enhancing low-frequency response for deep, punchy bass that you can feel.

Whether you're upgrading your daily driver or building a louder system, this loaded enclosure offers a perfect balance of power, efficiency, and reliability.

What’s Included

• (1) DS18 Dual 12” Loaded Subwoofer Enclosure (ZR12.4D)

System Specifications

• Total RMS Power: 1500W
• Total MAX Power: 3000W
• Final Impedance: 1 Ohm
• Sensitivity: 86 dB
• Frequency Response: 20Hz – 200Hz
• Recommended LPF: 70Hz

Subwoofer Details

• Model: ZR12.4D
• Voice Coil: Dual 2 Ohm (DVC)
• Power Handling (Each): 750W RMS / 1500W MAX
• Magnet: Ferrite (100 oz)
• Basket: Steel

Enclosure Specifications

• Type: Ported
• Tuning Frequency: 29 Hz
• Material: 3/4" MDF
• Configuration: Dual 12”

Dimensions

• Height: 14.48"
• Width: 36.22"
• Depth (Top): 19.68"
• Depth (Bottom): 21.65"
